    Digital band selective Global Repeater Full Band System

    Ask Lasest Price
    Brand Name : ATNJ
    Model Number : AT-GLO
    Certification : CE,ROHS,CCC,TUV,BV, ISO
    Price : USD+1100---1250+kit
    Payment Terms : T/T, Western Union,Paypal,Alibaba,Bank transfering.
    Supply Ability : 100+unit+per Month.
    Delivery Time : 45 work days
    • Product Details
    • Company Profile

    Digital band selective Global Repeater Full Band System

    Digital Selection Adjustable Global Repeater Full Band System


    General :
    The Repeater provides an affordable solution to solve indoor signal coverage problems due to signal fading and attenuation caused by architectural obstacles. And its easy installation and maintenance can help carriers get fast returns.
    The repeater is working as a relay between the BTS and mobiles. It picks up the strongest signal from BTS via the Donor Antenna, linearly amplifies the signal, and then retransmits it via the Indoor Signal Distribution System to the weak/blind coverage area. The mobile signal is also amplified and retransmitted to the BTS via the opposite direction.


    Features:

    1. Digital bandwidth-adjustable features allow for seamless adaptability to different bands.
    2. Working for all mobile operators worldwide flexibly.
    3. Auto isolation detection.
    4. Improve any three mobile networks at the same time.
    5. Built-in Auto Gain Control (AGC)& Auto Level Control (ALC).
    6. Center frequency movable.
    7. OMS Lite for remote/local control and monitoring(Optional)

    Technical Specifications:

    FrequencyS1S2S3
    700+900/800/850MHz1700/1800/1900/2100MHzFDD2600/TDD2600/3500MHz
    (Tunable)(Tunable)(Tunable)
    Max. GainUplink70±3dB
    Downlink75±3dB
    Manual Gain Control31 dB in step of 1 dB
    Automatic Gain Control≧ 20 dB
    Gain Flatness (per sub-band)≦ ±3 dB (peak-to-peak)
    Max. Input Power Without Damage0 dBm
    Output PowerUplink17±2 dBm
    Downlink20±2 dBm
    Spurious Emission9KHz-1GHz≦ -36dBm
    1GHz-12.75GHz≦ -30dBm
    ACRR±20/100MHz≦-36dBc/30KHz
    ±40/200MHz≦-40dBc/30KHz
    EVM≦ 8%
    Frequency Stability≦ ±0.01 ppm
    Noise Figure≦ 8dB
    VSWR≦ 1.8
    System Delay≦ 4.5 µs
    RF ConnectorN-Female
    Impedance50 Ω
    Power SupplyAC 100/ 24 V
    Power Consumption≦ 120 W
    Dimensions350*303*81mm
    Weight≦ 8kgs
    IP RatingIP40
    Operating Temperature-25 °C to 55 °C








    FAQ

    1. Are you trading company or manufacturer ? Could I use our own logo and label?

    We are factory, with trading service. We provide OEM/OEM service.

    2. Can I have a sample order? What is your MOQ?
    Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

    3: Is it easy to set up your items?
    A: Yes. We have a user manual and support technical support 24/7.

    4. What is your warranty time?
    We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.
