    Band N77 N78 5G Mobile Signal Booster LTE 4G repeater 5G amplificador de seal celular

    Ask Lasest Price
    Brand Name : ATNJ
    Model Number : AS-LTE+5G
    Certification : CE,ROHS,CCC,TUV,BV, ISO
    Price : USD+450---580+kit
    Payment Terms : T/T, Western Union,Paypal,Alibaba,Bank transfering.
    Supply Ability : 1000+unit+per day.
    Delivery Time : 3-5 work days
    • Product Details
    • Company Profile

    Band N77 N78 5G Mobile Signal Booster LTE 4G repeater 5G amplificador de seal celular

    Band N77 N78 5G Mobile Signal Booster LTE 4G repeater 5G amplificador de seal celular


    General


    The 5G Pico Repeater provides an affordable solution to solve the indoor signal coverage problems due to signal fading and attenuation caused by architecture obstacles. And its easy installation and maintenance can help carrier get fast return.
    The repeater is working as a relay between the BTS and mobiles. It picks up the strongest signal from BTS via the Donor Antenna, linearly amplifies the signal and then retransmits it via the Indoor Signal Distribution System to the weak/blind coverage area. And the mobile signal is also amplified and retransmitted to the BTS via the opposite direction.


    5G Signal Booster 1800MHz + N77 Customized 3300 - 4200MHz Cellular Signal Repeater Amplifier


    How does it work?


    1. RECEIVES SIGNAL

    The powerful antenna reaches out to access a good signal, and delivers it to the booster.


    2. BOOSTS SIGNAL

    The booster receives the signal, amplifies it, and serves as a relay between your phone and the nearest cell tower.


    3. BROADCASTS SIGNAL

    Your devices get increased cell reception, and calls and data are fed through the booster back to the network.


    Technical Specifications

    LTE 1800 Performance Characteristics


    Uplink

    Downlink

    Remark

    Frequency range

    1710MHz-1785 MHz

    1805 MHz-1880 MHz


    Bandwidth

    75 MHz

    75 MHz


    Output power

    17±2dBm

    17±2dBm


    Device gain

    60±3dB

    65±3dB


    ALC/AGC Range

    ≥30dB

    ≥30dB


    Noise

    ≤9dB

    ≤9dB


    Ripple in band

    ≤8dB

    ≤8dB


    VSWR

    ≤2.0dBm

    ≤2.0dBm


    ACLR(dBc)

    ≤-36

    ≤-36


    Time delay

    ≤3.0μs

    ≤3.0μs



    Spurious emission

    9kHz~150kHz

    ≤-36dBm @1kHz


    150kHz~30MHz

    ≤-36dBm @10kHz


    30MHz~1GHz

    ≤-36dBm @100kHz


    1GHz~12.75GHz

    ≤-30dBm @1MHz


    EVM

    ≤3.5%

    ≤3.5%


    TDD-NR 3300---4200 Performance Characteristics


    Uplink

    Downlink


    Frequency range

    3300MHz-4200MHz or 3300MHz-4200MHz


    Bandwidth

    100 MHz


    Output power

    17±2dBm

    17±2dBm


    Device gain

    60±3dB

    60±3dB


    ALC/AGC Range

    ≥30dB

    ≥30dB


    Noise

    ≤9dB

    ≤9dB


    Ripple in band

    ≤5dB

    ≤5dB


    VSWR

    ≤2.0dBm

    ≤2.0dBm


    ACLR(dBc)

    ≤-36

    ≤-36


    Time delay

    ≤3.0μs

    ≤3.0μs



    Spurious emission

    9kHz~150kHz

    ≤-36dBm @1kHz


    150kHz~30MHz

    ≤-36dBm @10kHz


    30MHz~1GHz

    ≤-36dBm @100kHz


    1GHz~12.75GHz

    ≤-30dBm @1MHz


    256QAM EVM

    ≤3.5%

    ≤3.5%


    Performance Characteristics

    Working voltage

    DC 5.0V


    Working current

    ≤3.0A


    Power adapter input voltage

    AC 100~240V,50/60Hz


    Power comsumption

    ≤15W


    Enviroment temperature

    -25℃~+55℃


    relative humidity

    ≤85%


    Device connection type

    SMA-J


    Power port

    KLD-35-13


    Device size

    205×170×38mm


    Weight

    ≤1Kg


    Further detail pls click here for downloading the products specification:

    1800MHz+N77 N78 A034 5G Signal Repeater.pdf


    Selling Point



    ⭐ Intelligent to guide the installation with LCD .

    ⭐ Real time display the signal strength .

    ⭐ Automatic dormancy when no user make the calling .

    ⭐ Automatic alarm when installation mistake and provide the according solution .

    ⭐ Automatic adjust the system gain to avoid the repeater self-excitation .

    ⭐ Initiative reminding when the device was damaged .

    ⭐ Supports from 0.2 to 20MHz bandwidth adjusted(Customized) .
    ⭐ Supports 5G bandwidth, 40MHz,50MHz,60MHz,70MHz,80MHz,90MHz,100MHz(Frequency Bandwidth Customized) .

    ⭐With WIFI Monitor+Control(Customized),NMS(network management system),Function Optional .

    ⭐ A variety of appearance customization.



    Item Description


    Dual Band 5G Signal Booster 1800MHz+N41 2600MHz Plastic Material Mobile Signal Repeater 0Dual Band 5G Signal Booster 1800MHz+N41 2600MHz Plastic Material Mobile Signal Repeater 1

    Dual Band 5G Signal Booster 1800MHz+N41 2600MHz Plastic Material Mobile Signal Repeater 2


    The repeater makes the signal stronger in places with poor signal coverage such as:


    1) Underground areas: basements, parking lots, tunnels;


    2) Other places where cellular signal is shielded by metal or concrete walls: offices, supermarkets, cinemas, hotels;


    3) Places distant from the BTS like private houses.


    900MHz 1800MHz GSM Signal Booster For Home Dual Band 5dB Low Noise 9

    Mobile Signal Booster 70dB Gain Dual Band 800/1800MHz Cellular 2G 4G Repeater Amplifier 11

    Dual Band 5G Signal Booster 1800MHz+N41 2600MHz Plastic Material Mobile Signal Repeater 5



    FAQ:


    1. Are you trading company or manufacturer ? Could I use our own logo and label?

    We are the factory, with good trading service. We provide OEM/OEM service.

    2. Can I have a sample order? What is your MOQ?
    Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

    3.
    How do I determine the best place to set up my booster?


    How to select the best location is described fully in The installation guide. However, if you still cannot find a good place, you can contact us through chat or by email and we will help you with the setup.

    4. What is your warranty time?
    We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.

    5. Please feel free to contact us if there are any other questions.
